Galvanised Round Tubing

Stock range:

25.4×2.0mm through to 101×2.0mm.

Used for:

  • Specified in the shadeport industry, as Pre-galvanised material is not acceptable. Ours is all hot dipped galvanised.

Various lengths between 4.5m and 7.2m available.

Mass Charts

Round Tubing

Outside diameter

(mm)

Wall thickness t (mm)
1.6 2.0 2.5 3.0 3.5 4.0 4.5 5.0 6.0
15.8 0.564
19.1 0.689 0.841
21.4 0.783 0.959 1.17 1.36
25.4 0.939 1.15 1.41
26.9 1.00 1.23 1.51 1.78
32.0 1.19 1.47 1.80 2.13
34.1 1.28 1.59 1.95 2.30 2.64 2.97
38.1 1.44 1.78 2.20 2.60 2.99
42.8 1.63 2.02 2.49 2.95 3.39 3.83
48.5 1.85 2.29 2.83 3.36 3.88 4.38 4.88
50.8 1.91 2.37 2.93 3.48 4.08 4.62
57.1 2.19 2.72 3.37 4.01 4.63 5.24
60.3 2.32 2.88 3.57 4.24 4.91 5.56 6.20
63.5 2.44 3.03 3.76 4.48 5.18 5.87 6.55
76.2 2.94 3.66 4.55 5.42 6.28 7.12 7.96 8.78 10.39
88.9 3.45 4.29 5.33 6.36 7.37 8.38 9.37 10.35 12.27
101.6 3.95 4.91 6.11 7.30 8.47 9.63 10.78 11.91 14.15
114.3 5.54 6.89 8.24 9.57 10.88 12.19 13.48 16.03
127.0 6.17 7.68 9.18 10.66 12.14 13.60 15.05 17.91
139.7 10.12 11.76 13.39 15.01 16.61 19.79
152.4 11.06 12.85 14.64 16.41 18.18 21.67
165.1 12.00 13.95 15.89 17.83 19.74 23.55
177.8 12.93 15.05 17.07 19.15 21.31 25.42
193.7 16.42 21.00 27.78
219.1 18.60 23.81 31.52

Download PDF

Colour code relating to the grade of steel

SAE 1008 (Si less than 0.03)
SABS 1431  S355
