Cold Rolled Rectangular Tube
Cold Rolled Rectangular Tube is precision-formed steel tubing with a smooth finish and rectangular profile, designed for fabrication, structural frames, and general steel manufacturing
- Description
- Specifications
- Additional information
Description
Cold Rolled Rectangular Tube is a precision-formed steel tubing product designed for applications that require clean lines, structural reliability, and consistent dimensional accuracy. Produced through a cold rolling process, the tubing offers a smooth surface finish and uniform profile, making it well suited to fabrication, architectural steelwork, manufacturing, and general construction. Its rectangular shape provides strong load distribution and stability, making it a practical choice for frames, supports, gates, and structural components where both strength and appearance are important.
Key Features
- Rectangular steel profile provides strong support and stability for structural and fabrication work
- Cold rolled manufacturing process produces a smooth finish and accurate dimensions
- Available in a wide range of sizes including 20x10mm up to 76.2×38.10mm
- Multiple wall thickness options from 0.90mm to 2.00mm depending on size
- Suitable for welding, cutting, and fabrication across many steel applications
- Versatile steel tubing option for structural, architectural, and manufacturing use
Applications
- Structural frames and steel supports
- Gates, fencing, and balustrade fabrication
- Furniture and shopfitting structures
- General engineering and steel manufacturing
Cold Rolled Rectangular Tube | |||||||||||||||||
Outside Diameter | |||||||||||||||||
| 20.00 x 10 | 25.4 x 9.53 | 25.40 x 12.7 | 27 x 12 | 31.75 x 12.7 | 31.75 x 15.88 | 31.7 x 19.05 | 38.1 x 12.7 | 38.01 x 19.05 | 38.10 x 25.40 | 50.8 x 10.00 | 50.80 x 12.7 | 50.8 x 25.4 | 60 x 25 | 76.2 x 25.4 | 76.2 x 38.10 | ||
| Wall Thickness | 0.90 mm | 0,403 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
| 1.20 mm | 0,528 | 0,621 | 0,68 | – | 0,8 | – | – | 0,904 | 1,039 | 1,159 | 1,092 | – | 1,403 | – | 1,966 | – | |
| 1.6 mm | – | 0,813 | 0,938 | 0,939 | 1,05 | 1,131 | 1,208 | – | 1,370 | 1,515 | – | 1,515 | 1,842 | 2,068 | 2,441 | 2,694 | |
| 2.00 mm | – | – | – | – | – | 1,381 | – | – | 1,693 | – | – | – | 2,29 | – | – | – | |
Mass Kg/Mtr | |||||||||||||||||
Additional information
| Wall Thickness | 0.90mm, 1.20mm, 1.60mm, 2.00mm |
|---|---|
| Outside Diameter | 20.00 x 10.00mm, 25.40 x 12.70mm, 25.40 x 9.53mm, 27.00 x 12.00mm, 31.70 x 19.05mm, 31.75 x 12.70mm, 31.75 x 15.88mm, 38.01 x 19.05mm, 38.10 x 12.70mm, 38.10 x 25.40mm, 50.80 x 10.00mm, 50.80 x 12.70mm, 50.80 x 25.40mm, 60.00 x 25.00mm, 76.20 x 25.40mm, 76.20 x 38.10mm |
